Products Description
What is the Fiberglass grating?
Fiberglass grating is a glass fiber as an enhanced material. It is unsaturated polyester resin or anticorrosive ethylene resin as the substrate. A plate-shaped material with many spaces with special processing is composed.
Features of FRP Cover:
● Corrosion, acid and alkalinity, light and high-quality
● Flame retardant, insulation, strong sex
● Anti-slip, aging resistance, long life
● Anti-fading, anti-rust
● Strong design
Fibreglass grating color:
Commonly used is yellow, black, gray, green, blue, red, and color can be selected at will. Can customize the color according to the requirements of the customer to improve the environment of production venues.
Fibreglass grating size:
The commonly used size is 25, 30, 38, 40, 45, 50, 65mm, etc., which can be customized according to customer requirements. It is flexible and diverse, easy to cut, and stable size.
Product Specification
Resin Type
| Resin Type | Resin Matrix | Product Property | Rate of Flame Retardant | Maximum Temperature |
| Type VE | VE | Excellent corrosion resistance; acid, alkali, solvent or acid-base alternate and other harsh corrosion environments. | Flame retardant grade, flame propagation index < 10 | 230°F / 110°C |
| Type I | ISO | Excellent corrosion resistance; can withstand medium concentrations of inorganic acids, bases, and various salts. | Flame retardant grade, flame propagation index < 25 | 221°F / 105°C |
| Type F | Food Resin | The isopheryl food-grade resin has good corrosion resistance like isopheryl resin. | Flame retardant grade, flame propagation index < 30 | 221°F / 105°C |
| Type O | Ortho | General corrosion resistance; can withstand seawater, weak acid, and atmospheric aging environments. | Flame retardant grade, flame propagation index < 25 | 212°F / 100°C |
Type VE: Used in acid, alkali, solvent or acid-base alternating and other adverse corrosion environments.
Type I: Suitable for acidic or alkaline corrosion general environments.
Type F: Used in meat products, food processing, and waterworks.
Type O: Used in general corrosion environments, weak alkali corrosion, and atmospheric aging.
size Sheets
| No. | Mold Size (mm) | Thickness (mm) | Mesh Size (mm) | Quantity (set) | Weight (kg/m²) |
| 1 | 1000×4036 | 25 | 38×38.1 | 2 | 12.2 |
| 2 | 1220×4000 | 25 | 38×38 | 2 | 12.2 |
| 3 | 1220×4040 | 25 | 38×38 | 2 | 12.2 |
| 4 | 1220×3660 | 30 | 38×38 | 2 | 15 |
| 5 | 1220×4083 | 30 | 38×38 | 2 | 15 |
| 6 | 1000×4083 | 30 | 38×38 | 2 | 15 |
| 7 | 1000×4036 | 38 | 38×38.1 | 2 | 19.1 |
| 8 | 1220×3660 | 38 | 38×38 | 2 | 19.1 |
| 9 | 1220×4040 | 38 | 38×38 | 3 | 19.1 |
| 10 | 1220×4920 | 38 | 38×38 | 1 | 19.1 |
| 11 | 1007×3007 | 40 | 40×40 | 3 | 19.54 |
| 12 | 1007×4047 | 40 | 40×40 | 3 | 19.54 |
| 13 | 1247×4047 | 40 | 40×40 | 1 | 19.54 |
| 14 | 1247×4047 | 50 | 40×40 | 1 | 25 |
| 15 | 1007×4047 | 25 | 40×40 | 1 | 12.5 |
| 16 | 1220×4025 | 50 | 50×50 | 2 | 23.52 |
| 17 | 1000×4083 (Mini mesh) | 30 | 19×19 / 38×38 | 1 | 19 |
| 18 | 1220×4040 (Mini mesh) | 30 | 19×19 / 38×38 | 1 | 19 |
| 19 | 1220×4040 (Mini mesh) | 38 | 19×19 / 38×38 | 1 | 23.65 |
| 20 | 1247×4047 (Mini mesh) | 14 | 40×40 / 20×20 | 1 | 10.5 |
| 21 | 1247×4047 (Mini mesh) | 22 | 40×40 / 20×20 | 1 | 14.8 |
| 22 | 1527×4047 (Mini mesh) | 30 | 40×40 / 20×20 | 1 | 18.3 |
Application of Fibreglass grating
| Industry/Category | Specific Facilities/Items |
| Sewage Treatment | Sewage treatment plant, sewage purification plant, water treatment workshop. |
| Water Treatment | Maintenance walkway, ditch cover, large - container, cleaning device, pollution grid, flowing sink, biochemical water treatment pool hanging, ventilation window, staircase, cooling tower operation table shop surface. |
| Chemical Plants | Chemical plant, chemical operation platform, pH adjustment plants, smelting plants, steel mills, saltwater workshops, machinery factories, staircase platforms, operating platforms, double-floor systems, ditch covers, and covers drains, desalination units, detectors, disinfection systems, double covers. |
| Car Washing Lot 45 Shop | Car washing room drainage board, parking space, car washing house trench cover plate. |
| Garden Greening, Municipal Engineering | Tree pool cover, tree sirius , tree protection board. |
| Petroleum Industry | Maritime Petroleum Platform, Shipyard, Shipping deck. |
| Textile Factory | Replace metal grille, wooden platforms and cover cement floor, next to the dye tank, floor, nearby valve, etc. |
| Power Plant | Chemical water workshop ditch cover, waste pool, etc. |
| Metal Surface Treatment | Electroplating plant, pharmaceutical factory, battery plant, line board factory, pickled liquid field, surrounding machines, surrounding high - corrosion containers, electroplating wire aisles, double floor ground ground. |
Fibreglass Grating in the Construction Industry
Fibreglass grating is widely used in the construction industry due to its durability, corrosion resistance, and low maintenance requirements.
Staircases and Landing Platforms
Fibreglass grating is used in the construction of stair treads and landing platforms, providing slip resistance and durability in areas with high foot traffic.
In environments prone to moisture, such as basements or underground areas, fibreglass grating ensures safety and longevity without the risk of rust or decay.
Flooring Systems
- Raised Flooring Systems: In data centers, control rooms, and offices, fibreglass grating can be used as part of raised flooring systems to provide easy access to electrical wiring, plumbing, or cables while maintaining airflow underneath the floors.
- Industrial Flooring: Used in manufacturing plants or warehouses, where the grating's strength and resistance to chemicals are required for heavy-duty applications.
Our Product Advantages
Long Service Life with Low Maintenance Cost
Fibreglass grating can last 20-30 years or more, significantly outlasting traditional materials.
Fibreglass grating resists corrosion, rust, and decay, making it ideal for harsh environments like marine, industrial, or wastewater applications.
Unlike steel or wood, fibreglass grating requires minimal upkeep:
- No rust or corrosion: No need for costly treatments like painting or galvanizing.
- Impact resistant: It doesn't crack or splinter, reducing repair costs.
- Easy cleaning: Simple washing or scrubbing is usually enough to keep it in good condition.
- Periodic inspection: Only occasional checks for structural integrity are needed.
High Cost-Effectiveness
· Lightweight
Fibreglass grating is much lighter than traditional materials like steel or wood, making it easier to handle and transport during installation.
· Easy Cutting and Assembly
The material is simple to cut and shape, allowing for quick customization on-site to fit specific project requirements.
· Reduced Installation Time
Due to its ease of handling and assembly, installation time is significantly reduced, lowering overall labor costs.
.
Environmentally Friendly and Energy Efficient
· No Painting or Anti-Corrosion Treatment
Fibreglass grating does not require painting or regular anti- corrosion treatments, reducing the need for harmful chemicals and paints that contribute to environmental pollution.
· Minimizes Secondary Pollution
By eliminating the need for coatings, fibreglass grating helps to minimize secondary pollution, promoting cleaner and safer work environments.
· Meets Green Building Standards
Fibreglass grating complies with green building standards, making it a sustainable choice for eco-conscious projects and reducing environmental impact.
Minimal Maintenance Needs
· Corrosion Resistance
Naturally resistant to rust, corrosion, and chemical degradation, fibreglass grating performs well in harsh environments like marine, industrial, and wastewater settings, unlike steel or wood that degrade over time.
· No Need for Coatings or Painting
Unlike steel grating, fibreglass does not require anti-corrosion treatments, reducing ongoing maintenance costs for re-coating or replacements.
· Impact Resistance
Fibreglass is resistant to physical wear and tear, making it ideal for high-traffic areas. It won't crack or splinter, unlike wood or concrete, reducing repair needs.
· No Special Cleaning Requirements
It can be cleaned easily with basic methods, unlike metal grating that may corrode when exposed to harsh cleaning chemicals.
Production Workshop
Advanced Resin Mixing Systems
Qualification Guarantee
Our Certificate
ISO14001
ISO9001
ISO45001
SGS
FAQ
Q: 1. What is FRP grating used for?
A: FRP grating is widely used in industrial platforms, walkways, drainage covers, and offshore facilities due to its corrosion resistance, strength, and anti-slip performance.
Q: 2. Can FRP grating be used outdoors?
A: Yes, our FRP gratings are UV-resistant and weatherproof, making them ideal for outdoor applications such as chemical plants, docks, and rooftops.
Q: 3. Is fiberglass grating stronger than steel?
A: FRP grating offers high strength-to-weight ratio. While it's lighter than steel, it still provides excellent load-bearing capacity and resists corrosion in harsh environments.
Q: 4. Do you offer anti-slip FRP grating?
A: Absolutely. All our FRP gratings are available with anti-slip surface treatments, including gritted top and concave surface designs for maximum safety.
Q: 5. What colors are available for FRP gratings?
A: We offer standard colors like grey, green, and yellow. Custom colors are available upon request to meet your design or safety marking needs.
Q: 6. Can I request a free sample before ordering?
A: Yes, we provide free FRP grating samples. Just cover the shipping cost or contact us directly to arrange a sample shipment.
📧 Email: info@preet.cn
📲 WhatsApp: +86-13851475666
Q: 7. What sizes and mesh types do you offer?
A: We provide molded FRP grating in various mesh sizes (e.g. 38x38mm, 25x100mm) and thicknesses (e.g. 25mm, 38mm). Custom panel sizes and cutting services are available.
Q: 8. How can I order or get a quote?
A: Feel free to contact us with your specifications.
📧 Email: info@preet.cn
📲 WhatsApp: +86-13851475666
We'll reply within 24 hours with full details and pricing.
